Application of sand making machine
Our sand making machine is a newly researched equipment, with international advanced level. Technology and modern processing equipment make it a leading role in this industry.
The sand making machine also called vertical shaft impact crusher,sand maker.
It is widely used for medium and fine crushing (sand making) for various hard and brittle materials such as rocks, grinding materials, refractory materials, cement clinker, quartz, iron ore and concrete aggregate, etc. It is especially appropriate for sandstone for architecture and road construction.
Features of sand making machine
1.simple structure
2.low cost on operation
3. High efficiency & low consumption
4. the max humidity is 8%
5.It is suitable for crushing mid-hardness and high-hardness materials
6. working noise less than 75 decibels
7.dust pollution is little
Advantages of sand making machine
The supplies are falling into the whirling impeller of high speed vertically by the top of the machine, under high-speed centrifugal function, the supplies shunted with another part around the impeller in the form of the umbrella produce at a high speed, striking and crushing. Supplies which not bumping into each other, can form vortex striking with each other between impeller and chassis. The crushed materials will be discharged from the underpart directly, forming a lot of circulation of closed path. They will be sieved by the equipment and reaches the grain size of finished product required.
- Place of Origin: Henan, China (Mainland)
- Brand Name: Dajia-Mining
- Model Number: 750
- Weight: 7300.000 kg
- :
- :
- :
- :
- :
- :
- :
- :
- :
Specifications of sand making machine
Model | ImpellerSpeed (r/min) | Max Feed-in size(mm) | Capacity(t/h) | MotorPower(KW) | Weight(T) | Overall Dimensions (mm) |
600 | 2000-3000 | 30 | 12-30 | 2*30 | 5.6 | 2800*ø1500*2030 |
750 | 1500-2500 | 35 | 25-55 | 2*45 | 7.3 | 3300*ø1800*2440 |
900A | 1200-2000 | 40 | 55-100 | 2*55 | 12.1 | 3750*ø2120*2660 |
900B | 1000-1450 | 40 | 65-130 | 2*75 | 13.6 | 3750*ø2300*2090 |
1050 | 1000-1700 | 45 | 100-160 | 2*(90-110) | 16.9 | 4480*ø2450*2906 |
1250 | 850-1450 | 45 | 160-300 | 2*(132-180) | 22 | 4563*ø2650*3716 |
1350 | 800-1193 | 50 | 200-360 | 2*(180-220) | 26 | 5340*ø2940*3650 |
