- Place of Origin: Henan, China (Mainland)
- Brand Name: Dajia-Mining
- Model Number: PEF350*750
- Weight: 12500.000 kg
- :
- :
- :
- :
- :
- :
- :
- :
- :
Structures and working principle:
The structure of jaw crusher contains the frame, eccentric shaft, big belt pulley, flywheel, movable jaw, side guard plate, toggle plate, rear seat of toggle plate, modulation gap screw, returning spring, fixed jaw plate and movable jaw plate, etc, among which the toggle plate is used for safety. The working mode of this series jaw crusher is pressing deviously.
This crushing machine working theory is: The motor drives belt and belt wheel, the eccentric shaft causes the movable jaw to move down and up, forward and backward, the angle between toggle plate and movable jaw becomes bigger when the movable jaw moves up, so that the movable jaw moves toward the fixed jaw, and the materials are pressed, crushed, or cut, as a result, the aim of crushing is accomplished.
Features and Benefits of Jaw Crusher
1. High capacity
2 . Very reliable
3 . Adjustable for easy wear parts
4 . Good protection against overloading
5 . Simple structure and easy operation
6 . Longer service time
7 . Easy replacement of wear and spare parts
8 . Low cost and easy to install
9 . Wider range to suit specific needs
- Place of Origin: Henan, China (Mainland)
- Brand Name: Dajia-Mining
- Model Number: PEF350*750
- Weight: 12500.000 kg
- :
- :
- :
- :
- :
- :
- :
- :
- :
Specifications of Jaw Crusher
Model | Technical Performance | Power (kw) | Overall Dimensions (mm) | Weight (kg) | |||
Max. Feeding Size (mm) | Adjustment scopes (mm) | Capacity (m3/h) | Rotating speed of main shaft (r/min) | ||||
PEF150×250 | 125 | 10-40 | 1-3 | 285 | 7.5 | 922×745×933 | 700 |
PEF200×300 | 165 | 20-70 | 2-8 | 265 | 11 | 1056×1100×1120 | 800 |
PEF250×400 | 210 | 20-80 | 5-20 | 310 | 18.5 | 1108×1142×1392 | 3000 |
PEF400×600 | 340 | 40-90 | 10-40 | 275 | 30 | 1700×1732×1392 | 7200 |
PEF350×750 | 290 | 30-55 | 20-50 | 300 | 37 | 1900×1806×1808 | 8900 |
PEF500×750 | 425 | 50-100 | 34-68 | 275 | 55 | 2050×1860×2145 | 11320 |
PEF600×900 | 480 | 75-200 | 40-120 | 255 | 75 | 2792×2168×2250 | 17600 |
PEF750×1060 | 630 | 80-200 | 80-160 | 250 | 90 | 4180×2560×3070 | 30530 |
PEF900×1200 | 750 | 100-200 | 110-200 | 250 | 110 | 5200×2900×3500 | 50000 |
PEF1200×1500 | 1020 | 150-300 | 220-400 | 180 | 160 | 4200×3300×3500 | 106000 |
PEX150×750 | 125 | 10-40 | 5-15 | 300 | 15 | 1220×1480×1180 | 3600 |
PEX250×1000 | 210 | 15-55 | 10-32 | 300 | 37 | 1580×1992×1380 | 7350 |
PEX250×1200 | 210 | 15-60 | 12-38 | 300 | 37 | 1530×2192×1380 | 8700 |
PEX300×1300 | 250 | 20-90 | 16-65 | 300 | 55 | 1930×2400×1747 | 11600 |
