- Place of Origin: Henan, China (Mainland)
- Brand Name: Dajia-Mining
- Model Number: Lime500
- Weight: 3800.000 kg
- :
- :
- :
- :
- :
- :
- :
Lime Rotary Kiln
Lime rotary kiln is widely used in various industries: dolomite, kaolin clay, bauxite, refractory furnace charge titanium, cement, limestone, iron powder, vanadium ore, activated carbon, coke, mineral powder, aluminum oxide, magnesium oxide, zinc oxide, etc.
Structures of lime rotary kiln
The lime kiln mainly consists of kiln body,loading device, burning deice,unloading device,electronic appliance,duct collection,etc.Different lime kilns have different structures,their process flow are almost the same.But the equipment value has big distinction,of course the result are different.
Features of lime rotary kiln
High production Capacity
Effective improve the firing Temperature,lower fuel consumption
Fully from the normal preheating temperature
Can directly calcining 10-15 fine fraction limestone
Widely range to row and fuel materials,unobstructed air,eduction sulfur smoke timely;
Stable quality.
- Place of Origin: Henan, China (Mainland)
- Brand Name: Dajia-Mining
- Model Number: Lime500
- Weight: 3800.000 kg
- :
- :
- :
- :
- :
- :
- :
Main Equipments Data
| Capacity (tpd) | 150 | 200 | 225 | 250 | 300 | 400 | 500 | 600 | 800 |
| Rotary kilnv (m) | 2.8×55 | 2.8x43 | 3x50 | 3.2x50 | 3.3x55 | 3.6x55 | 3.8x55 | 4x60 | 4.3x60 |
| Slope % | 3.5 | 3.5 | 3.5 | 3.5 | 3 | 3 | 3 | 3 | 3 |
| Calcination temp.(°C) | 1300 | 1300 | 1300 | 1350 | 1350 | 1350 | 1350 | 1350 | 1350 |
| Fuel (coal) | Gas/powder | Gas/powder | Gas/powder | Gas/powder | Gas/powder | Gas/powder | Gas/powder | Gas/powder | Gas/powder |
| Fuel consumption (kJ/kg) | 6670 | 5500 | 5400 | 5400 | 5400 | 5300 | 5250 | 5200 | 5000 |
| Preheating equipment | Square | Square | Square | Square | Polygonal | Polygonal | Polygonal | Polygonal | |
| Cooling equipment | Vertical cooling | Vertical cooling | Vertical cooling | Vertical cooling | Vertical cooling | Vertical cooling | Vertical cooling | Vertical cooling |
